2-8 Chapter 2: Hardware information
2.2.5 Layout contents
Slots/Soocket Page
1. CPU sockets 2-10
2. DDR3 sockets 2-17
3. PCI slot 2-22
4. PCI Express x 8 slots (x8/x4 link) 2-22
5. PCI Express x 16 slot (x16/x8 link) 2-22
6. PIKE slot 2-22
Jumpers Page
1. Clear RTC RAM (CLRTC1) 2-25
2. VGA controller setting (3-pin VGA_SW1)) 2-26
3. DDR3 voltage control setting
(4-pin LVDDR3_SEL1; LVDDR3_SEL2)
2-26
4. LAN controller setting (3-pin LAN_SW1, LAN_SW2) 2-27
5. CPU Fan and Chassis Fan control setting
(3-pin CPUFAN_SEL1, CHAFAN_SEL1)
2-27
6. Force BIOS recovery setting (3-pin RECOVERY1) 2-28
Rear panel connectors Page
1. PS/2 mouse port (green) 2-29
2. RJ-45 port for iKVM 2-29
3. PS/2 keyboard port (purple) 2-29
4. USB 2.0 ports 1 and 2 2-29
5. Serial (COM1) port 2-29
6. Video Graphics Adapter port 2-29
7. LAN 1 (RJ-45) port 2-29
8. LAN 2 (RJ-45) port 2-29
