Page 68

2 - 2 4

C h a p t e r 2 : B I O S s e t u p

2.4.5

Chipset

The Chipset menu allows you to change the advanced chipset settings.
Select an item then press to display the sub-menu.

Advanced Chipset Settings

Configure DRAM Timing by SPD

[Enabled]

Hyper-Path 2

[Auto]

Graphic Adapter Priority

[PCI Express/PCI]

PEG Buffer Length

[Auto]

Link Latency

[Auto]

PEG Link Mode

[Auto]

PEG Root Control

[Auto]

Slot Power

[Auto]

Configure DRAM Timing by SPD [Enabled]

When this item is enabled, the DRAM timing parameters are set according
to the DRAM SPD (Serial Presence Detect). When disabled, you can
manually set the DRAM timing parameters through the DRAM sub-items.
Configuration options: [Disabled] [Enabled]

The following sub-items appear when the C o n f i g u r e D R A M T i m i n g

C o n f i g u r e D R A M T i m i n g

b y S P D

b y S P D item is set to [Disabled].

Hyper Threading Technology [Enabled]

Allows you to enable or disable the processor Hyper-Threading Technology.
Configuration options: [Disabled] [Enabled]

DRAM CAS# Latency [3 Clocks]
Controls the latency between the SDRAM read command and the time
the data actually becomes available. Configuration options: [3 Clocks]
[2.5 Clocks] [2 Clocks]

DRAM RAS# Precharge [4 Clocks]
Controls the idle clocks after issuing a precharge command to the DDR
SDRAM. Configuration options: [2 Clocks] [3 Clocks] [4 Clocks]
[5 Clocks]

DRAM RAS# to CAS# Delay [4 Clocks]
Controls the latency between the DDR SDRAM active command and
the read/write command. Configuration options: [2 Clocks] [3 Clocks]
[4 Clocks] [5 Clocks]
