Asus P4GPL-X User Manual
Page 70

2 - 2 6
2 - 2 6
2 - 2 6
2 - 2 6
2 - 2 6
C h a p t e r 2 : B I O S s e t u p
C h a p t e r 2 : B I O S s e t u p
C h a p t e r 2 : B I O S s e t u p
C h a p t e r 2 : B I O S s e t u p
C h a p t e r 2 : B I O S s e t u p
2.4.6
2.4.6
2.4.6
2.4.6
2.4.6
Onboard Devices Configuration
Onboard Devices Configuration
Onboard Devices Configuration
Onboard Devices Configuration
Onboard Devices Configuration
Configure Win627EHF Super IO Chipset
HD Audio Controller
[Enabled]
Onboard LAN
[Enabled]
LAN Option ROM
[Disabled]
Serial Port1 Address
[2F8/IRQ3]
Parallel Port Address
[378]
Parallel Port Mode
[ECP]
ECP Mode DMA Channel
[DMA3]
Parallel Port IRQ
[IRQ7]
HD Audio Controller [Enabled]
HD Audio Controller [Enabled]
HD Audio Controller [Enabled]
HD Audio Controller [Enabled]
HD Audio Controller [Enabled]
Enables or disables the onboard High-Definition Audio controller.
Configuration options: [Enabled] [Disabled]
Onboard LAN [Enabled]
Onboard LAN [Enabled]
Onboard LAN [Enabled]
Onboard LAN [Enabled]
Onboard LAN [Enabled]
Allows you to enable or disable the onboard PCI Express Gigabit LAN
controller. Configuration options: [Enabled] [Disabled]
LAN Option ROM [Disabled]
Allows you to enable or disable the option ROM in the onboard LAN
controller. This item appears only when the Onboard LAN item is set
to [Enabled]. Configuration options: [Disabled] [Enabled]
Serial Port1 Address [2F8/IRQ3]
Serial Port1 Address [2F8/IRQ3]
Serial Port1 Address [2F8/IRQ3]
Serial Port1 Address [2F8/IRQ3]
Serial Port1 Address [2F8/IRQ3]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [2F8/IRQ3] [3F8/IRQ4] [3E8/IRQ4]
[2E8/IRQ3]
Parallel Port Address [378]
Parallel Port Address [378]
Parallel Port Address [378]
Parallel Port Address [378]
Parallel Port Address [378]
Allows you to select the Parallel Port base addresses.
Configuration options: [Disabled] [378] [278] [3BC]
