1 - 1 6 1 - 1 6 1 - 1 6 1 - 1 6 1 - 1 6 C h a p t e r 1 : P r o d u c t i n t r o d u c t i o n C h a p t e r 1 : P r o d u c t i n t r o d u c t i o n C h a p t e r 1 : P r o d u c t i n t r o d u c t i o n C h a p t e r 1 : P r o d u c t i n t r o d u c t i o n C h a p t e r 1 : P r o d u c t i n t r o d u c t i o n
L e g e n d : L e g e n d : L e g e n d : L e g e n d : L e g e n d :
S S - S S - S S - S S - S S - Single Sided
D S - D S - D S - D S - D S - Double Sided
C L - C L - C L - C L - C L - CAS Latency
A A A A A - supports one module inserted into either slot, in a Single-channel memory
configuration.
B B B B B - supports one pair of modules inserted into both blue slots as one pair of
Dual-channel memory configuration.
Visit the ASUS website (www.asus.com) for the latest Qualified Vendors
List.
Recommended memory configurations Recommended memory configurations Recommended memory configurations Recommended memory configurations Recommended memory configurations
S o c k e t s S o c k e t s S o c k e t s S o c k e t s S o c k e t s
M o d e M o d e M o d e M o d e M o d e D I M M _ A 2 D I M M _ A 2 D I M M _ A 2 D I M M _ A 2 D I M M _ A 2 D I M M _ B 2 D I M M _ B 2 D I M M _ B 2 D I M M _ B 2 D I M M _ B 2
( b l u e ) ( b l u e ) ( b l u e ) ( b l u e ) ( b l u e ) ( b l u e ) ( b l u e ) ( b l u e ) ( b l u e ) ( b l u e )
Single-channel (1) Populated —
(2) — Populated
Dual-channel (1) Populated Populated
DDR400 Qualified Vendors List DDR400 Qualified Vendors List DDR400 Qualified Vendors List DDR400 Qualified Vendors List DDR400 Qualified Vendors List
D I M M s u p p o r t D I M M s u p p o r t D I M M s u p p o r t D I M M s u p p o r t D I M M s u p p o r t
S i z e S i z e S i z e S i z e S i z e V e n d o r V e n d o r V e n d o r V e n d o r V e n d o r M o d e l M o d e l M o d e l M o d e l M o d e l B r a n d B r a n d B r a n d B r a n d B r a n d S i d e ( s ) C o m p o n e n t S i d e ( s ) C o m p o n e n t S i d e ( s ) C o m p o n e n t S i d e ( s ) C o m p o n e n t S i d e ( s ) C o m p o n e n t C L A C L A C L A C L A C L A B B B B B
256 MB KINGSTON KVR400X64C3A/256 Hynix SS HY5DU56822BT-D43 – • •
512 MB KINGSTON KVR400X64C3A/512 Hynix DS HY5DU56822BT-D43 – • •
512 MB KINGSTON KVR400X64C3A/512 Infineon DS HYB25D256809BT-5B – • •
1024 MB KINGSTON KVR400X64C3A/1G N/A DS HYB25D512800BE-5B 3 • •
256 MB SAMSUNG M368L3223FTN-CCC SAMSUNG SS K4H560838F-TCCC 3 • •
512 MB SAMSUNG M368L6523BTM-CCC SAMSUNG SS K4H510838B-TCCC 3 • •
256 MB MICRON MT8VDDT3264AG-40BCB MICRON SS MT46V32M8TG-5BC – • •
512 MB MICRON MT16VDDT6464AG-40BCB MICRON DS MT46V32M8TG-5BC – • •
256 MB Infineon HYS64D32300HU-5-C Infineon SS HYB25D256800CE-5C 3 • •
512 MB CORSAIR CMX512-3200C2 Winbond DS N/A 2 • •
512 MB CORSAIR VS512MB400 VALUE seLecT DS VS32M8-5 2.5 • •
256 MB Hynix HYMD232645D8J-D43 Hynix SS HY5DU56822DT-D43 3 • •
512 MB Hynix HYMD264646D8J-D43 Hynix DS HY5DU56822DT-D43 3 • •
