xii
P7P55D-E Deluxe specifications summary
CPU LGA1156 socket for Intel ® Core™ i7 / Core™ i5 / Core™ i3
processors
Supports Intel ® Turbo Boost Technology
* Refer to www.asus.com for Intel CPU support list
Chipset Intel ® P55 Express Chipset
Memory 4 x DIMM, max. 16GB, DDR3 2200(O.C.)* / 1600 / 1333 /
1066 MHz, non-ECC, un-buffered memory
Dual channel memory architecture
Supports Intel ® Extreme Memory Profile (XMP)
* Hyper DIMM support is subject to the physical characteristics
of individual CPUs. Some hyper DIMMs only support one
DIMM per channel. Please refer to Memory QVL for details.
** Refer to www.asus.com or this user manual for the
Memory QVL (Qualified Vendors Lists)
Expansion Slots 2 x PCI Express 2.0 x16 slots (single at x16 or dual at x8 / x8
mode)
3 x PCI Express 2.0 x1 slots (2 at 5.0GT/s [blue]; 1 at 2.5GT/s
[gray])
2 x PCI slots
Multi-GPU Support Supports ATI ® Quad-GPU CrossFireX™ Technology
Supports NVIDIA ® Quad-GPU SLI™ Technology
Storage Intel ® P55 Express Chipset:
- 6 x SATA 3.0 Gb/s ports
- Intel ® Matrix Storage supporting SATA RAID 0,1, 5, and 10
JMicron ® JMB363 SATA & PATA controller:
- 1 x Ultra DMA 133/100/66 for up to 2 PATA devices
- 1 x SATA 3.0 Gb/s port (black)
- 1 x External SATA port
Marvell
® PCIe SATA 6Gb/s controller:
- 2 x SATA 6.0 Gb/s ports (gray)
LAN Dual Gigabit LAN controllers
- 2 x Realtek ® 8112L Gigabit LAN controller featuring AI NET2
USB NEC USB 3.0 controller:
- 2 x USB 3.0 ports (blue; at back panel)
Intel
® P55 Express Chipset:
- 12 x USB 2.0 ports (6 ports at mid-board, 6 ports at back
panel)
IEEE 1394 VIA ® VT6308P controller supports 2 x IEEE 1394a ports
(one at midboard; one at back panel)
Audio VIA ® VT2020 10-channel High Definition Audio CODEC
- Absolute Pitch BD192/24 featuring ENVY HD
- BD Audio Layer Content Protection
- DTS Surround Sensation Ultra-PC
- Supports Jack-Detection, Multi-streaming and Front Panel
Jack-Retasking
- Coaxial / Optical S/PDIF out ports at back I/O
- ASUS Noise Filter
(continued on the next page)
