3-22 Chapter 3: BIOS setup
Chapter 3
Blue Yellow Purple Red
IMC Voltage
1.10000V–
1.16875V
1.17500V–
1.22500V
1.23125V–
1.30000V
1.30625V–
1.90000V
DRAM Voltage
1.5000V–
1.5625V
1.5750V–
1.6250V
1.6375V–
1.6875V
1.7000V–
2.5000V
CPU PLL Voltage
1.8000V–
1.8625V
1.8750V–
1.9250V
1.9375-
1.9875
2.0000V
PCH Voltage
1.0500V-
1.1875V
1.2000V
1.3000V
1.3125V
1.4500V
1.4625V-
2.0000V
3.5.20 DRAM DATA REF Voltage on CHA/B [Auto]
Allows you to set the DRAM DATA Reference Voltage on Channel A/B. The values
range from 0.395x to 0.630x with a 0.005x interval. Different ratio might enhance DRAM
overclocking ability.
3.5.21 DRAM CTRL REF Voltage on CHA/B [Auto]
Allows you to set the DRAM Control Reference Voltage on Channel A/B. The values
range from 0.395x to 0.630x with a 0.005x interval. Different ratio might enhance DRAM
overclocking ability.
3.5.22 Load-Line Calibration [Auto]
[Auto] Automatic configuration.
[Disabled] Follow Intel specifications.
[Enabled] Improve CPU VDroop directly.
3.5.23 CPU Spread Spectrum [Auto]
[Auto] Automatic configuration.
[Disabled] Enhances the BCLK overclocking ability.
[Enabled] Sets to [Enabled] for EMI control.
3.5.24 PCIE Spread Spectrum [Auto]
[Auto] Automatic configuration.
[Disabled] Enhances the PCIE overclocking ability.
[Enabled] Sets to [Enabled] for EMI control.
