ASUS P5QPL-VM 2-13
Overclock Options [Overclock 5%]
Allows you to select the overclock options. Configuration options: [Overclock 5%]
[Overclock 10%] [Overclock 15%] [Overclock 20%] [Overclock 30%] [Test Mode]
DRAM Frequency [Auto]
Allows you to set the DDR2 operating frequency. Configuration options: [Auto] [667 MHz]
[800 MHz] [1067 MHz]
Selecting a very high DRAM frequency may cause the system to become unstable! If this
happens, revert to the default setting.
The following item appears only when you set the AI Overclocking item to [Overclock
Profile].
FSB
DRAM Frequency
Auto 667MHz 800MHz 960MHz 1000MHz 1067MHz 1100MHz 1200MHz
1333 • • • • •
1066 • • • •
800 • • •
The DRAM Frequency options vary with different FSB value. Refer to the following table for
the DRAM Frequency options when the FSB value is 1333, 1066, and 800.
PCI Express Frequency [Auto]
Allows you to select the PCI Express frequency. Configuration options: [Auto] [90] [91]
[92]~[150]
Memory Voltage
Allows you to set the Memory Voltage. Key in the value directly. Use +/- to adjust the voltage.
The increment is 0.00625V. The standard value is 1.85000V.
Configuration options: [Auto] [Min = 1.850000V] [Max = 2.24375V]
NB Voltage [Auto]
Allows you to select the North Bridge voltage or set it to [Auto] mode.
Configuration options: [Auto] [1.125V] [1.175V] [1.225V] [1.275V]
SB 1.5 Voltage [1.5V]
Allows you to select the South Bridge voltage.
Configuration options: [1.5V] [1.6V]
CPU VTT [1.2V]
Allows you to select FSB termination voltage. Configuration options: [1.2V] [1.3V]
CPU Vcore offset [Auto]
Allows you to select CPU Vcore Voltage or set to [Auto] mode.
Configuration options: [Auto] [0mv] [50mv] [100mv] [150mv]
