3-20 Chapter 3: BIOS setup
3.4.11 CPU Differential Amplitude [Auto]
Different AMP might enhance BCLK overclocking ability.
Configuration options: [Auto] [7��mV] [8��mV] [9��mV] [1���mV]
3.4.12 CPU Clock Skew [Auto]
Adjusting this item may help enhancing BCLK overclocking ability. You may need
to adjust the NB Clock Skew item at the same time.
Configuration options: [Auto] [Normal] [Delay 1��ps]–[Delay 15��ps]
The following ten (10) items are adjusted by typing the desired values using
the numeric keypad and press the key. You can also use the <+> and
<-> keys to adjust the value. To restore the default setting, type [auto] using the
keyboard and press the key.
3.4.13 CPU Voltage Mode [Offset]
Allows you to set the CPU Voltage Mode. Different sub-items appear according to
the CPU Voltage Mode item setting. Configuration options: [Offset] [Manual]
Offset Voltage [Auto]
This item appears only when you set the CPU Voltage Mode item to [Offset]
and allows you to set the Offset voltage. The values range from 0.00625V to
0.50000V with a 0.00625V interval.
Offset Sign [-]
This item appears only when you set the Offset Voltage item to a value other
than [Auto].
[+]
To offset the voltage by a positive value.
[–] To offset the voltage by a negative value.
Fixed Voltage [Auto]
This item appears only when you set the CPU Voltage Mode item to
[Manual] and allows you to set a fixed CPU voltage. The values range from
0.85V to 2.10V* with a 0.00625V interval.
Refer to the CPU documentation before setting the CPU Vcore voltage. Setting
a high VCore voltage may damage the CPU permanently, and setting a low
VCore voltage may make the system unstable.
3.4.14 IMC Voltage [Auto]
Allows you to set the CPU Integrated Memory Controller voltage. The values range
from 1.1V to 1.9V* with a 0.00625V interval.
