3-14 Chapter 3: BIOS setup
�.�.6 AHCI Configuration
This menu is the section for AHCI configuration. It appears only when you set the
item Configure SATA as from the sub-menu of SATA Configuration to [AHCI].
BIOS SETUP UTILITY
Main
AHCI Settings
SATA Port1 [Not Detected]
SATA Port2 [Not Detected]
SATA Port3 [Not Detected]
SATA Port4 [Not Detected]
SATA Port5 [Not Detected]
SATA Port6 [Not Detected]
Some SATA CD/DVD in
AHCI mode need to
wait ready longer.
SATA Port1 [Auto]
Allows you to select the type of device connected to the system.
Configuration options: [Auto] [Not Installed]
SMART Monitoring [Enabled]
Allows you to set the Self-Monitoring, Analysis and Reporting Technology.
Configration options: [Disabled] [Enabled]
SATA Port1–6 [XXXX]
Displays the status of auto-detection of SATA devices.
BIOS SETUP UTILITY
Main
SATA Port1
Device :Not Detected
SATA Port1 [Auto]
SMART Monitoring [Enabled]
Select the type
of devices connected
to the system.
3.3.7 System Information
This menu gives you an overview of the general system specifications. The BIOS
automatically detects the BIOS information, CPU specification, and system memory
in this menu.
BIOS SETUP UTILITY
Main
BIOS Information
BIOS Version : 0503
BIOS Build Date : 08/28/09
EC BIOS Version : MBEC-0028
Processor
Type : Intel(R) Xeon(R) CPU X3440 @
2.53GHz
Speed : 2533MHz
System Memory
Usable Size : 1016MB
