xii
P7P55 WS Supercomputer
specifications summary
CPU Quad Core intel Xeon 3400 series Server Processor
Quad Core intel Core i7-800 series Desktop Processor
Quad Core intel Core i5-700 series Desktop Processor
Dual Core 32nm CPU design Ready
Chipset Intel ® P55 Express Chipset/ Nvidia NF200*1
Memory 4 x DIMM, max. 16GB, DDR3 2133(OC)*/1600/1333/
1�66 MHz, non�ECC, un�buffered memory 1�66 MHz, non�ECC, un�buffered memory
Dual channel architecture
Support Intel Extreme Memory Profile (XMP)
*Due to Intel spec definition, DIMMs of DDR3�1333 or
above are supported by specific CPU models only.
*Please load X.M.P in BIOS for hyper DIMM (DDR3
1333MHz or above) support.
Expansion Slots 2 x PCIe 2.0 x16 (@ x16 or x8)
2 x PCIe 2.0 x16 (@ x8)
1 x PCIe x16 (@ x4)
1 x PCIe x1 (@ x1)
1 x PCI
Multi-GPU Technology Supports NVIDIA ® Geforce 3 way/2 way SLI™
technology technology
Supports ATI ® CrossFireX™ technology, up to Quad
CrossFireX™
Storage Intel® P55 Express Chipset
- 6 x SATA 150/300
6 x SATA 150/300
- Intel Intel ® Matrix Storage supporting SATA RAID 0, 1,
10, and 5
LAN 2 x Realtek 8112L Dual Gb LAN
- Support teaming function
High Definition Audio ALC12���GR , 8 channels High Definition Audio CODEC
- Multi-Streaming
- Jack-Sensing
- Front Panel Jack-Retasking
- Coaxial / Optical S/PDIF out ports at back I/O
- ASUS Noise-Filer
IEEE 1394 VIA VT6308S controller supports 2 x 1394a ports
(continued on the next page)
