ASUS P5N73-AM 2-13
Memory Timing Setting
The following items become user-configurable when the Memory Timing Setting item is
set to [Expert].
Memory Timing Setting [Optimal]
Allows you to set the memory timing setting. Configuration options: [Optimal] [Expert]
tCL (CAS Latency) [Auto]
Allows you to set tCL (CAS Latency). Configuration options: [Auto] [1] [2] [3] [4] [5] [6].
tRCD [Auto]
Allows you to set RAS to CAS delay for a RD/WR command to the same bank.
Configuration options: [Auto] [1] [2] [3] [4] [5] [6] [7]
tRP [Auto]
Allows you to set the row precharge time Precharge-to-Active or Auto-Refresh of the
same bank. Configuration options: [Auto] [1] [2] [3] [4] [5] [6] [7]
tRAS [Auto]
Allows you set the minimum RAS active time. Configuration options: [Auto] [1] [2] [3] [4]
[5] [6] [7]...[31]
Command Per Clock (CMD) [Auto]
Allows you to command timing setting (per clock unit). Configuration options: [Auto] [1
clock] [2 clock]
**Advanced Memory Settings**
tRRD [Auto]
Allows you to set tRRD. Configuration options: [Auto] [1] [2] [3] [4] [5] [6]...[15].
tRC [Auto]
Allows you set the RAS to RAS or auto refresh time of the same bank. Configuration
options: [Auto] [1] [2] [3] [4] [5] [6] [7]...[31]
tWR [Auto]
Allows you set the tWR. Configuration options: [Auto] [1] [2] [3] [4] [5] [6]
tWTR [Auto]
Allows you set the tWTR. Configuration options: [Auto] [1] [2] [3] [4] [5] [6] [7]...[15]
tREF [Auto]
Allows you set the tREF. Configuration options: [Auto] [1] [2]
1.8VDual Over Voltage Control Default]
Allows you to adjust the +1.8V dual over voltage. Configuration options: [Default] [+6.25mV]
[+12.50mV] [+18.75mV]...[+393.75mV]
1.35V Over Voltage Control [Disabled]
Allows you to adjust the +1.35V over voltage. Configuration options: [Enabled] [Disable]
VCORE Over Voltage Control [Disabled]
Allows you to adjust the VCORE over voltage. Configuration options: [Disabled] [+50 mV]
[+100 mV] [+150 mV]
