3-24 Chapter 3: BIOS setup
Chapter 3
3.5.7 Onboard Devices Configuration
Scroll down to view the other BIOS items.
ASM1061 Storage Controller (Rear) [Enabled]
Allows you to select the ASM1061 storage controller operating mode.
[Disabled]
Disables the ASM1061 storage controller.
[Enabled] Enables the ASM1061 storage controller.
ASM1061 Storage OPROM [Enabled]
This item appears only when you set the previous item to [Enabled] and allows you to enable
or disable the OptionRom of the ASM1061storage controller.
Configuration options: [Enabled] [Disabled]
ASM1061 Storage Controller (Front) [Enabled]
Allows you to select the ASM1061 storage controller operating mode.
[Disabled]
Disables the ASM1061 storage controller.
[Enabled] Enables the ASM1061 storage controller.
ASM1061 Storage OPROM [Enabled]
This item appears only when you set the previous item to [Enabled] and allows you to enable
or disable the OptionRom of the ASM1061storage controller.
Configuration options: [Enabled] [Disabled]
Main Ai Tweaker Advanced Monitor Boot Tool
Exit
Version 2.00.1208. Copyright (C) 2012 American Megatrends, Inc.
Enabled/Disabled ASM1061 Storage
OPROM
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Shortcut
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
Back Advanced\ Onboard Devices Configuration >
UEFI BIOS Utility - Advanced Mode
ASM1061 Storage Controller (Rear) Enabled
ASM1061 Storage OPROM Enabled
ASM1061 Storage Controller (Front) Enabled
ASM1061 Storage OPROM Enabled
Asmedia USB 3.0 Controller (USB3_12) Enabled
Asmedia USB 3.0 Controller (USB3_34) Enabled
Asmedia USB 3.0 Controller (Front) Enabled
Asmedia USB 3.0 Battery Charging Support Disabled
Realtek LAN Controller Enabled
Realtek PXE OPROM Disabled
S3 Video Repost Disabled
> Serial Port Configuration
> SB HD Azalia Configuration
