ASUS SABERTOOTH 990FX R2.0 1-7
Chapter 1
Layout contents
Connectors/Jumpers/Slots Page
1. ATX power connectors (24-pin EATXPWR, 8-pin EATX12V) 1-33
2. AM3+ CPU socket 1-8
3. CPU, chassis, and optional fan connectors (4-pin CPU_FAN,
4-pin CPU_OPT, 4-pin CHA_FAN1-4 )
1-31
4. DDR3 DIMM slots 1-9
5. MemOK! button 1-22
6. USB 3.0 connector (20-1 pin USB3_56) 1-27
7. AMD ® Serial ATA 6.0 Gb/s connectors (7-pin SATA6G_1-6 [brown]) 1-26
8. ASmedia ® Serial ATA 6.0 Gb/s connectors
(7-pin SATA6G_E12 [gray])
1-27
9. Direct connector (2-pin DRCT) 1-35
10. System panel connector (20-8 pin PANEL) 1-34
11. DirectKey button 1-23
12. Serial port connector (10-1 pin COM1) 1-30
13. Clear RTC RAM (3-pin CLRTC) 1-24
14. USB 2.0 connectors (10-1 pin USB1314, USB1112) 1-29
15. Standby power LED 1-25
16. TPM connector (20-1 pin TPM) 1-35
17. Front panel audio connector (10-1 pin AAFP) 1-32
18. Digital audio connector (4-1 pin SPDIF_OUT) 1-28
