xii
SABERTOOTH 990FX R2.0 specifications summary
Back Panel I/O ports 1 x PS/2 keyboard/mouse combo port
1 x Optical S/PDIF Output port
2 x eSATA 6Gb/s ports [red]
1 x USB BIOS Flashback button
1 x LAN (RJ-45) port
4 x USB 3.0/2.0 ports [blue]
8 x USB 2.0/1.1 ports
6 x Audio jacks for 8-channel Audio I/O ports
Internal I/O connectors 1 x USB 3.0/2.0 connector (supports additional 2 19-pin USB
3.0/2.0 ports [moss green])
2 x USB 2.0/1.1 connectors (support additional 4 USB 2.0/1.1 ports)
6 x SATA 6Gb/s connectors [brown]
2 x SATA 6Gb/s connectors [gray]
1 x CPU Fan connector (4-pin)
1 x CPU Optional fan connector (4-pin)
4 x Chassis fan connectors (4-pin)
1 x TPM header
1 x COM connector
1 x S/PDIF Out header
1 x DirectKey button
1 x DRCT header
1 x MemOK! button
1 x Clear CMOS jumper
24-pin EATX power connector
8-pin EATX 12V power connector
Front panel audio connector
System panel (Q-Connector)
BIOS features 64 Mb Flash ROM, UEFI BIOS, PnP, SLP2.1, DMI 2.0, WfM 2.0,
SM BIOS 2.7, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2,
F12 PrintScreen function, F3 Shortcut function, and ASUS DRAM
SPD (Serial Presence Detect) memory information
Manageability WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
Support DVD contents Drivers
ASUS Utilities
ASUS Update
Anti-virus software (OEM version)
Form factor ATX form factor: 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
Specifications are subject to change without notice.
