Asus Terminator A7VT User Manual
Page 38
38
Chapter 2: Basic Installation
5.
Fit the rail tabs on the sides
and bottom of the cover to the
edges of the chassis.
6.
Push the cover towards the
rear until it fits. The locking tab
snaps into the hole on the
chassis indicating that the
cover is in place.
Locking tab hole
Locking tab
Firmly push the cover to ensure that it is fully engaged to the chassis.
7.
Lock the cover with the screw
on the rear panel.
Rail tabs
