Chapter 2: Basic Installation
2.11.2 UAEX module
The system front I/O panel has a UAEX module that contains the front
panel I/O ports and the connectors to the motherboard.
Connector locations on the motherboard
Connect to USB34 connector
on the motherboard
Connect to MIC_LOUT
connector on the motherboard
MIC_LOUT connector
(for Microphone/Line Out cable)
USB34
USB56
®
J1
USB
T
: Port0
B: Port1
MIC
HPHONE1
J2
UAEX
