ASUS P7F7-E WS Supercomputer 3-15
3.4 Ai Tweaker menu
The Ai Tweaker menu items allow you to configure overclocking-related items.
Take caution when changing the settings of the Ai Tweaker menu items.
Incorrect field values can cause the system to malfunction.
The default values of the following items vary depending on the CPU and
memory modules you install on the motherboard.
v02.61 (C)Copyright 1985-2009, American Megatrends, Inc.
BIOS SETUP UTILITY
Main AI Tweaker Advanced Power Boot Tools Exit
Warning: this function
belongs to overclock-
ing, and it may cause
instability.
Select a CPU level,
and the rest will be
auto-adjusted. If you
want to adjust more,
set Ai Overclock Tuner
to Manual after you
select a CPU level.
←→ Select Screen
↑↓ Select Item
+- Change Field
F1 General Help
F10 Save and Exit
ESC Exit
Configure System Performance Settings
Target CPU Frequency: 2793MHz
Target DRAM Frequency: 1333MHz
CPU Level Up [Auto]
Ai Overclock Tuner [Auto]
CPU Ratio Setting [22.0]
Intel(R) SpeedStep(TM) Tech [Enabled]
Intel(R) TurboMode tech [Enabled]
Xtreme Phase Full Power Mode [Auto]
DRAM Frequency [Auto]
QPI Frequency [Auto]
ASUS/3rd Party UI Priority [ASUS Utility]
OC Tuner [Turbo Profile]
Start auto tuning
DRAM Timing Control
v02.61 (C)Copyright 1985-2009, American Megatrends, Inc.
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
CPU Differential Amplitude [Auto]
CPU Clock Skew [Auto]
******* Please key in numbers directly! *******
CPU Voltage Mode [Offset]
Offset Voltage [Auto]
Current CPU Core Voltage [ 1.200V]
IMC Voltage [Auto]
Current IMC Voltage [ 1.106V]
DRAM Voltage [Auto]
Current DRAM Voltage [ 1.506V]
CPU PLL Voltage [Auto]
Current CPU PLL Voltage [ 1.896V]
PCH Voltage [Auto]
Current PCH Voltage [ 1.050V]
***********************************************
Load-Line Calibration [Auto]
CPU Spread Spectrum [Auto]
PCIE Spread Spectrum [Auto]
Scroll down to display the following items:
