Dual Channel Memory configuration table for Clarkdale CPU

A3

A2

A1

B3

B2

B1

1 DIMM

—

—

—

—

—

SS/DS

1 DIMM

—

—

SS/DS

—

—

—

1 DIMMs

—

—

—

—

SS/DS

—

1 DIMMs

—

SS/DS

—

—

—

—

2 DIMMs

—

—

SS/DS

—

—

SS/DS

2 DIMMs

—

SS/DS

—

—

SS/DS

—

4 DIMMs

—

SS/DS

SS/DS

—

SS/DS

SS/DS

(SS = Single-sided; DS = Double sided; “—” = No memory)

2-12

Chapter 2: Hardware information
