3-26 Chapter 3: BIOS setup
�.5.� Onboard Devices Configuration
BIOS SETUP UTILITY
Advanced
Onboard Devices Configuration
HDA Controller [Enabled]
Front Panel Type [HD Audio]
Realtek LAN1 [Enabled]
Realtek LAN2 [Enabled]
LAN Boot ROM [Disabled]
Onboard 1394 Controller [Enabled]
Serial Port1 Address [3F8/IRQ4]
Marvell 9128 Controller [IDE Mode]
Options
Enabled
Disabled
HDA Controller [Enabled]
[Enabled] Enables the High Definition Audio Controller.
[Disabled] Disables the controller.
Front Panel Type [HD Audio]
[AC97]
Set the front panel audio connector (AAFP) mode to legacy AC’97.
[HD Audio] Set the front panel audio connector (AAFP) mode to high-
definition audio.
Realtek LAN1/2 [Enabled]
[Enabled] Enables Realtek LAN Controller 1/2.
[Disabled] Disables Realtek LAN Controller 1/2.
LAN Boot ROM [Disabled]
This item appears only when you enable the previous item(s).
[Disabled] Disables Realtek LAN Boot ROM.
[Enabled] Enables Realtek LAN Boot ROM.
Onboard 1394 Controller [Enabled]
[Enabled] Enables the onboard 1394 Controller.
[Disabled] Disables the controller.
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
Marvell 9128 Controller [IDE Mode]
Allows you to select the Marvell 9128 controller operate mode.
Configuration options: [Disabled] [IDE Mode] [AHCI Mode]
You have to manually install the Marvell RAID Utility (MRU) when this item is set
to [IDE Mode].
