xii
P7F7-E WS Supercomputer
specifications summary
CPU LGA 1156 socket for Intel ® Core™ i7/Core™ i5/Core™ i3/
Pentium ® desktop Processors
LGA 1156 socket for Intel 3400 series server processor
* The Intel Turbo Boost Technology support depends on
the CPU types.
** Refer to www.asus.com for Intel CPU support list
Chipset Intel ® 3450 Chipset
Nvidia NF200*1
Memory 6 x DIMM, max. 16GB, DDR3 2000(O.C.)* /1333 /1066/
800 MHz, non-ECC/ECC, un-buffered memory
Dual channel architecture
Support Intel Extreme Memory Profile (XMP)
* Due to Intel spec definition, DIMMs of DDR3-1333 or
above are supported by specific CPU models only.
* Please load X.M.P in BIOS for hyper DIMM (DDR3
1333MHz or above) support.
On-board VGA Multi-VGA output support: DVI-I and RGB ports
Supports DVI with max. resolution 1920 x 1200 @ 60Hz
Supports RGB with max. resolution 2048 x 1536 @ 75 Hz
Maximum shared memory of 1748 MB
Expansion Slots 2 x PCIe 2.0 x16 (@ x16 or x8)
2 x PCIe 2.0 x16 (@ x8)
3 x PCIe x1 (@ x1)
Multi-GPU Technology Supports NVIDIA ® Geforce 3 way/2 way SLI™
technology
Supports ATI
® CrossFireX™ technology, up to Quad
CrossFireX™
CUDA support Up to 3 NVIDIA Tesla cards + 1 NVIDIA Quadro card
Up to 4 NVIDIA Tesla cards (only for Clarkdale processor)
Storage Intel ® 3450 Chipset
- 6 x SATA 150/300 6 x SATA 150/300
- Intel Intel ® Matrix Storage supporting SATA RAID 0, 1,
10, and 5 10, and 5
Marvell ® PCIe SATA6Gb/s controller:
- 2 x SATA 6.0 Gb/s ports 2 x SATA 6.0 Gb/s ports
- Support SATA RAID 0 and 1
LAN 2 x Realtek 81112L Dual Gb LAN
- Support teaming function
USB NEC USB 3.0 controller
- 2 x USB 3.0 ports (Blue, at back panel)
Intel
® 3450 Ibex Peak
- 12 x USB 2.0 ports (6 ports at mid-board, 6 ports at
back panel)
(continued on the next page)
