10. USB 2.0 connector (10-1 pin USB56)
This connector is for the USB 2.0 port. Connect the USB module cable to this
connector, then install the module to a slot opening at the back of the system chassis.
This USB connector complies with USB 2.0 specification that supports up to 480Mbps
connection speed.
Never connect a 1394 cable to the USB connector. Doing so will damage the motherboard!
The USB 2.0 module is purchased separately.
F1A75-I DELUXE
F1A75-I DELUXE USB2.0 connector
PIN
1
USB+5V USB_P6- USB_P6+ GN
D
NC
USB+5V USB_P5- USB_P5+
GN
D
USB56
Chapter 1: Product introduction 1-28
