ASUS H87M-PLUS 1-7
Chapter 1
Layout contents
Connectors/Jumpers/Slots Page
1. CPU and chassis fan connectors (4-pin CPU_FAN, 4-pin CHA_FAN1/2) 1-19
2. ATX power connectors (24-pin EATXPWR, 8-pin EATX12V) 1-20
3. LGA1150 CPU socket 1-8
4. DDR3 DIMM slots 1-9
5. TPM header (20-1 pin TPM) 1-20
6. MemOK! button 1-14
7. Serial port connector (10-1 pin COM) 1-17
8. DRAM LED (DRAM_LED) 1-15
9. LPT connector (26-1 pin LPT) 1-16
10. USB 3.0 connector (20-1 pin USB3_12) 1-17
11. Intel ® H87 Serial ATA 6.0 Gb/s connectors (7-pin SATA6G_1-6) 1-16
12. Clear RTC RAM (3-pin CLRTC) 1-13
13. System panel connector (20-8 pin PANEL) 1-21
14. USB 2.0 connectors (10-1 pin USB910, USB1112, USB1314) 1-18
15. Standby power LED (SB_PWR) 1-15
16. Front panel audio connector (10-1 pin AAFP) 1-19
17. Digital audio connector (4-1 pin SPDIF_OUT) 1-18
