5-6 Chapter 5: BIOS setup
5.2.2 Menu bar
The menu bar on top of the screen has the following main items:
Main
For changing the basic system configuration
Advanced For changing the advanced system settings
Server For changing the advanced server settings
Boot For changing the system boot configuration
Exit For selecting the exit options and loading default settings
To select an item on the menu bar, press the right or left arrow key on the keyboard
until the desired item is highlighted.
5.2.3 Navigation keys
At the bottom right corner of a menu screen are the navigation keys for that
particular menu. Use the navigation keys to select items in the menu and change
the settings.
5.2.1 BIOS menu screen
Some of the navigation keys differ from one screen to another.
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
BIOS SETUP UTILITY
Main Advanced Server Boot Exit
Use [ENTER], [TAB]
or [SHIFT-TAB] to
select a field.
Use [+] or [-] to
configure system Date.
←→ Select Screen
↑↓ Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
Navigation keys
General help Menu bar
Sub-menu items
Configuration fields Menu items
System Time [13:44:30]
System Date [Wed, 12/17/2008]
Legacy Diskette A [1.44M, 3.5 in.]
SATA 1 : [ST3160812AS]
SATA 2 : [Not Detected]
SATA 3 : [Not Detected]
SATA 4 : [Not Detected]
SATA 5 : [Not Detected]
SATA 6 : [Not Detected]
IDE Primary Master : [Not Detected]
IDE Primary Slave : [Not Detected]
IDE Configuration
AHCI Configuration
System Information
