ASUS TS700-E6/RS8 6-31
Select a destination disk with the same size as the original hard disk.
[ DEGRADED VOLUME DETECTED ]
[↑↓]-Previous/Next [ENTER]-Select [ESC]-Exit
"Degraded" volume and disk available for rebuilding detected. Selecting
a disk initiates a rebuild. Rebuild completes in the operating system.
Select the port of destination disk for rebuilding (ESC to exit):
Port Drive Model Serial # Size
X XXXXXXXXXXX XXXXXXXX XX.XGB
6.3.7 Rebuilding the RAID
This option is only for the RAID 1 set.
Rebuilding the RAID with other non-RAID disk
If any of the SATA hard disk drives included in the RAID 1 array failed, the system
displays the status of the RAID volume as “Degraded” during POST. You can
rebuild the RAID array with other installed non-RAID disks.
To rebuild the RAID with other non-RAID disk:
1. At the prompt, press + to enter the Intel Matrix Storage Manager
option ROM utility.
2. If there is a non-RAID SATA Hard Disk available, the utility will prompt to
rebuild the RAID. Press , and then use up/down arrow keys to select
the destination disk or press to exit.
6.3.6 Exiting the Intel ® Matrix Storage Manager
To exit the utility
1. From the utility main menu, select 5. Exit, and then press . The
following warning message appears.
2. Press to exit or press to return to the utility main menu.
Are you sure you want to exit? (Y/N):
[ CONFIRM EXIT ]
