ASUS P5GC-VM 2-21
CPU Internal Thermal Control [Auto]
Disables or sets the CPU internal thermal control. Configuration options: [Auto]
[Disabled]
2.4.3 Chipset
The Chipset menu allows you to change the advanced chipset settings. Select an
item then press to display the sub-menu.
Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Advanced Chipset Settings
DRAM Frequency [Auto]
Configure DRAM Timing by SPD [Enabled]
Hyper Path 3 [Auto]
DRAM Throttling Threshold [Auto]
Boot Graphic Adapter Priority [PCI Express/Int-VG]
Internal Graphics Mode Select [Enabled, 8MB]
Graphics memory type [Auto]
Boot Display Device [Auto]
TV Connector [Auto]
HDTV Output [Auto]
TV Standard [VBIOS-Default]
PEG Buffer Length [Auto]
Link Latency [Auto]
PEG Root Control [Auto]
Slot Power [Auto]
High Priority Port Select [Disabled]
DRAM Frequency [Auto]
Allows you to set the DDR2 operating frequency. Configuration options: [Auto] [533
Mhz] [667 Mhz]
Configure DRAM Timing by SPD [Enabled]
When this item is enabled, the DRAM timing parameters are set according to the
DRAM SPD (Serial Presence Detect). When disabled, you can manually set the
DRAM timing parameters through the DRAM sub-items. The following sub-items
appear when this item is Disabled. Configuration options: [Disabled] [Enabled]
DRAM CAS# Latency [5 Clocks]
Controls the latency between the SDRAM read command and the time the
data actually becomes available. Configuration options: [6 Clocks] [5 Clocks]
[4 Clocks] [3 Clocks]
Selecting a very high DRAM frequency may cause the system to become
unstable! If this happens, revert to the default setting.
