5.3.4 5.3.4 5.3.4 5.3.4 5.3.4 Creating a RAID 1 (Mirror) set Creating a RAID 1 (Mirror) set Creating a RAID 1 (Mirror) set Creating a RAID 1 (Mirror) set Creating a RAID 1 (Mirror) set
You can create two types of mirrored configuration using the LSI Logic
Configuration Utility: Integrated Mirroring (IM) or RAID 1-E. See section
5.1.1 for RAID definitions.
To create an RAID 1 set:
1. From the R A I D P r o p e r t i e s R A I D P r o p e r t i e s R A I D P r o p e r t i e s R A I D P r o p e r t i e s R A I D P r o p e r t i e s screen, select the drives that you want
to include in the RAID 1 set.
For Integrated Mirrored array, select first the drive with data that you
want to retain. This drive will become the primary copy of the array.
• Integrated Mirrored array - Select a minimum of two drives
• RAID-1E - Select a minimum of four drives
The A r r a y A r r a y A r r a y A r r a y A r r a y label on top of the screen changes to IM or 1E depending
on the number of selected hard disk drives.
I n t e g r a t e d M i r r o r i n g I n t e g r a t e d M i r r o r i n g I n t e g r a t e d M i r r o r i n g I n t e g r a t e d M i r r o r i n g I n t e g r a t e d M i r r o r i n g
R A I D - 1 E R A I D - 1 E R A I D - 1 E R A I D - 1 E R A I D - 1 E
