5 - 4 5 - 4 5 - 4 5 - 4 5 - 4 C h a p t e r 5 : R A I D c o n f i g u r a t i o n C h a p t e r 5 : R A I D c o n f i g u r a t i o n C h a p t e r 5 : R A I D c o n f i g u r a t i o n C h a p t e r 5 : R A I D c o n f i g u r a t i o n C h a p t e r 5 : R A I D c o n f i g u r a t i o n
5.2.2 5.2.2 5.2.2 5.2.2 5.2.2 Entering the NVIDIA Entering the NVIDIA Entering the NVIDIA Entering the NVIDIA Entering the NVIDIA ® ® ® ® ® RAID Utility RAID Utility RAID Utility RAID Utility RAID Utility
To enter the NVIDIA ® RAID Utility:
1. Restart the computer.
2. During POST, press to display the utility main menu.
[F6] Back [F7] Finish [TAB] Navigate [
↑↓] Select [ENTER] Popup
NVIDIA RAID Utility Oct 5 2004
- Define a New Array -
RAID Mode: Striping Striping Block: Optimal
Free Disks Array Disks
Loc Disk Model Name Loc Disk Model Name
1.0.M XXXXXXXXXXXXXXXXXX
1.1.M XXXXXXXXXXXXXXXXXX
[
→] Add
2.0.M XXXXXXXXXXXXXXXXXX
2.1.M XXXXXXXXXXXXXXXXXX
[
←] Del
At the bottom section of the screen are the navigation keys. These keys
allow you to move through and select menu options.
[F6] Back [F7] Finish [TAB] Navigate [
↑↓] Select [ENTER] Popup
The navigation keys vary depending on the menu level or option.
