Creating a RAID 1 set (Mirror)

To create a RAID 1 set:

From the D e f i n e a N e w A r r a y

D e f i n e a N e w A r r a y

D e f i n e a N e w A r r a y menu, select R A I D M o d e

R A I D M o d e

R A I D M o d e, then

press . A pop-up menu appears.

Use the up or down arrow keys to select
M i r r o r i n g

M i r r o r i n g

M i r r o r i n g, then press .

Mirroring

Striping

Stripe Mirroring

Spanning

Press to move to the F r e e D i s k s

F r e e D i s k s

F r e e D i s k s section.

Highlight the hard disk drives that you want to add in the RAID set,
then press the right arrow key to select. The selected hard disk drives
appear in the A r r a y D i s k s

A r r a y D i s k s

A r r a y D i s k s section. Repeat the process until all

desired hard disk drives are added.

Clear disk data?

[Y] YES [N] Cancel

After selecting the hard disk drives, press
to create the RAID 1 set. A pop-up
window appears.

Press to delete all data from the hard disk drives and continue
creating the RAID set. Press to backup exisitng data to a target
hard disk drive.

You will lose all data on the drives if you clear the disk data!

The utility displays the created RAID 1 set. Press to save
your settings and exit the utility.0

[F6] Back [F7] Finish [TAB] Navigate [

↑↓] Select [ENTER] Popup

NVIDIA RAID Utility Oct 5 2004

- Define a New Array -

RAID Mode:

Mirroring

Striping Block:

Optimal

Free Disks

Array Disks

Loc Disk Model Name

1.0.M XXXXXXXXXXXXXXXXXX

1.1.M XXXXXXXXXXXXXXXXXX

[

→] Add

2.0.M XXXXXXXXXXXXXXXXXX
2.1.M XXXXXXXXXXXXXXXXXX

[

←] Del
