ASUS P8P67-M PRO 1-8
1.5.4 Layout contents
Connectors/Jumpers/Slots/LED Page Connectors/Jumpers/Slots/LED Page
1. ATX power connectors (24-pin EATXPWR,
8-pin EATX12V)
1-28 12. Intel ® P67 Serial ATA 3.0Gb/s connectors
(7-pin SATA3G_1~4 [blue])
1-31
2. CPU, chassis, and power fan connectors
(4-pin CPU_FAN, 4-pin CHA_FAN1/2,
3-pin PWR_FAN)
1-29 13. System panel connector (20-8 pin PANEL) 1-33
3. Intel ® LGA1155 CPU socket 1-9 14. Clear RTC RAM (3-pin CLRTC) 1-24
4. DDR3 DIMM slots 1-14 15. USB connectors (10-1 pin USB78, USB910,
USB1112, USB1314)
1-34
5. MemOK! switch 1-35 16. IEEE 1394a connector (10-1 pin IE1394_1) 1-27
6. DRAM LED (DRAM_LED) 1-36 17. LPT connector (26-1 pin LPT) 1-26
7. TPU switch 1-34 18. Serial port connector (10-1 pin COM1) 1-28
8. TPU LED (O2LED1) 1-36 19. Digital audio connector (4-1 pin SPDIF_OUT) 1-29
9. TPM connector (20-1 pin TPM) 1-32 20. Standby power LED (SB_PWR) 1-36
10. Marvell ® Serial ATA 6.0Gb/s connector (7-pin
SATA6G_E1 [navy blue])
1-30 21. Front panel audio connector (10-1 pin AAFP) 1-27
11. Intel ® P67 Serial ATA 6.0Gb/s connectors
(7-pin SATA6G_1/2 [gray])
1-32
