8x1 Regeneration Taps
11
Specifications
Environmental
Temperature: 0ºC to 40ºC (Operating), -10ºC to 70ºC (Storage)
Relative Humidity: 10% min, 95% max, non-condensing
Redundant Power Supplies, each
Input: 100-240VAC, 0.5A, 47-63Hz
DC Input: -48VDC nominal, -36 to -72VDC, 1A
Power Consumption: 50W
Mechanical
Dimensions: 1.75” high x 13” deep x 17” wide (19” rack mount, 1U)
Weight: TBA lbs
Connectors
Network: (2) RJ45 (copper models); (2) duplex LC type (fiber models)
Monitor: (16) RJ45 (copper models); (16) SFP/SFP+ (fiber models);
AC Power: Universal power cord plugs
DC Power: Terminal peak, 12-14 gauge wire
Indicators
Link and Activity LEDs on copper ports; Link LEDs on fiber network ports
SFP Present LEDs
Speed indication, 10/100/1000 model: Link LED is amber (10 Mbps),
yellow (100 Mbps) or green (1000 Mbps)
Two power LEDs for the redundant power supplies
Mode (speed and duplex) LEDs on 10/100/1000 models
Performance
Drops: No packets dropped from 0 to 1 Gbps (10 Gbps on 10G models)
Latency: TBA
Splitter (fiber models)
Split Ratio: 50/50 (other split ratios available on request)
Multimode Insertion Loss (network port): 4.5 dB max
Singlemode Insertion Loss (network port): 3.7 dB max
Fiber Optic Interface:
Laser: Class I, eye-safe, laser emitter type. These Class I Lasers conform to
the applicable requirements per US 21 CFR (J) and EN 60825-1, also UL
1950 applications
Optical Transmitter Wave Length: 850nm nominal (MM)
Output Power: -9.5 dB to -4 dB, Input Sensitivity: 0 dB to -17 dB
Optical Transmitter Wave Length: 1310nm nominal (SM)
Output Power: -10 dB to -3 dB, Input Sensitivity: -3 dB to -20 dB
Certifications
Safety: UL, CE
EMC: FCC, VCCI, C-Tick
Environmental: RoHS, WEEE
Protocol: IEEE 802.3 compliant
