TRANSISTOR OUTLINE PACKAGES
TO-5 and TO-8 CRYSTAL CLOCK OSCILLATORS
1.8 to 15Vdc - 0.045Hz to 125MHz
Transistor Outline Packages (Revision F, March 2011 ) (ECO# 10145)
Electrical Characteristics
Parameters C AC HC T L (*)
Output freq. range (Fo)
QT1, 14
244Hz — 15MHz
732.4Hz — 85MHz 732.4Hz — 125MHz
QT2 0.045Hz — 85MHz 0.045Hz — 85MHz
QT3 732.4Hz — 85MHz 732.4Hz — 85MHz
Supply voltage (Vdd) 5V ~ 15Vdc ± 10% 5.0Vdc ± 10% 3.3Vdc ± 10%
Maximum Applied Voltage (Vdd max.) -0.5 to +18Vdc -0.5 to +7.0Vdc -0.5 to +5.0Vdc
Freq. stability (∆F/∆T) See Option codes
Operating temp. (Topr) See Option codes
Storage temp. (Tsto) -62ºC to + 125ºC
Operating supply current
(Idd) (No Load)
F and Vdd dependent
3 mA max. at 5V up to 5MHz
25 mA max. at 15V up to 15MHz
20 mA max. - 0.045Hz ~ < 16MHz
25 mA max. - 16MHz ~ < 40MHz
35 mA max. - 40MHz ~ < 60MHz
45 mA max. - 60MHz ~ 85MHz
3 mA max. - 0.045Hz ~ < 500kHz
6 mA max. - 500kHz ~ < 16MHz
10 mA max. - 16MHz ~ < 32MHz
20 mA max. - 32MHz ~ < 60MHz
30 mA max. - 60MHz ~ < 100MHz
40 mA max. - 100MHz ~ 125MHz
Symmetry
(50% of ouput waveform or 1.4Vdc for
TTL) 45/55% max. Fo < 4MHz
40/60% max. Fo ≥ 4MHz 45/55% max. Fo < 12MHz
40/60% max. Fo ≥ 12MHz
Rise and Fall times
(with typical load)
30ns max.
(Measured from 10% to 90%)
15ns max. Fo < 15kHz
6ns max. Fo 15kHz ~ 39.999MHz
3ns max. Fo 40MHz ~ 125 MHz
(Measured from 10% to 90% CMOS or from 0.8V to 2.0V TTL)
Output Load
15pF // 10kΩ 10TTL Fo < 20MHz
6TTL Fo ≥ 20MHz
15pF // 10kΩ
Start-up time (Tstup) 10ms max.
Output voltage (Voh/Vol) 0.9 x Vdd min.; 0.1 x Vdd max. 2.4V min.; 0.4V max. 0.9 x Vdd min.; 0.1 x Vdd max.
Output Current (Ioh/Iol)
± 1mA typ. at 5V
± 6.8mA typ. at 15V ± 24mA ±8 mA -1.6mA / TTL
+40μA / TTL
± 4mA .
Enable/Disable
Tristate function Pin 1
Call for details
VIH ≥ 2.2V Oscillation;
VIL ≤ 0.8V High Impedance
VIH ≥ 0.7 x Vdd Oscillation;
VIL ≤ 0.3 x Vdd High Impedance
Jitter RMS 1σ (at 25ºC)
8ps typ. - < 40MHz
5ps typ. - ≥ 40MHz
15ps typ. - < 40MHz
8ps typ. - ≥ 40MHz
Aging (at 70ºC) ± 5ppm max. first year / ± 2ppm typ. per year thereafter
(*) Available in 2.5Vdc (N) or 1.8Vdc (R)
Z Output logic can drive up to 200 pF load with typical 6ns rise & fall times (tr, tf)
ECL, PECL, LVPECL are available. Please contact Q-Tech for details.
