OPTOTRONIC
®
OT 15/220-240/12 P
Constant Voltage LED Power supply for 12V LED - Modules
2013-03-21
AA416090055
OSRAM AG
www.osram.com
Steinerne Furt 62, 86167 Augsburg, Germany
No. 1, North Industrial Road
528000 Foshan Guangdong, P.R. China
Wiring and Connection
Ensure that the LED module load is within the range of rated voltage, current and power supply
(see Technical data)
Maximum output cable length is limited by EMI and cross diameter
Use output cable sections adequate to the load demand
The luminaire manufacturer is responsible for providing the required clearances and creepage
distances and also for protection against electrical shock, especially for the line and load wires
Please avoid direct exposure of sunlight and in case of exposure to UV rays, protect the cables with
suitable silicone sheath.
Earth Connection
OT 15/12 P is
a “Protection Class II” power supply, therefore ground connection is not required
Mounting and Environmental protection
The control gear is a build in type for luminaire integration
Maximum permissible ambient temperature must not be exceeded. Make sure there is adequate
space to avoid a build-up of heat. In critical installations the temperature at t
c
has to be controlled
2 General Note
Power supplies must be installed by a qualified electrician
Disconnected from mains supplies before wiring work
For further information see also “OPTOTRONIC – Technical guid
