Appendix
Technical data
Operating temperature 0 °C ... +50 °C
Transmission power 10 mW
Radio signal Frequency band 868.3 MHz
FSK digital signal (OSRAM-
specific coding)
Functional range In the open air: approx. 100 m
In buildings: approx. 30 m
Permissible conductor
cross-section when connec-
ted via terminals
Single-wire conductor
(AWG 26 – AWG 20):
0.13 - 0.5 mm²
Fine-wire conductor
(AWG 24 – AWG 20):
0.2 - 0.5 mm²
Max. number of
wall/hand-held transmitters
8
Protection class III
Protection type IP 20
Dimensions
(L x W x H)
118 x 30 x 21 mm
Disposal
Do not dispose of the device with household waste.
Electronic devices must be disposed of at local
recycling centres for waste electronic equipment in
accordance with EU Directive 2002/96/EC on waste
electrical and electronic equipment.
Conformity with the relevant EU directives is
confirmed by the CE symbol.
