Appendix – OSRAM Y-CONNECTOR User Manual
Page 2
Page 2 of 2
35 mm
16 mm
18 mm
Appendix
Technical data
Combined control and
supply connection
3x 4-pin modular 4p4c sockets
Basic insulation as per IEC 664
Connection cable
2x 4-pin modular 4p4c plug
Length: 2.1 m
Dimensions
(L x W x H)
35 x 18 x 16 mm
The CE requirements are fulfilled: EMC requirements as per
EN 61547, low voltage as per EN 60928.
Conformity with the relevant EU directives is
confirmed by the CE symbol.
