1: Introduction
2 JAZ-A-IRRAD-02-201011
Jaz Modules
Jaz consist of a stack of individual spectroscopic instruments specified by the user to suit their unique
application. Modules available for the Jaz stack to do irradiance measurements include the following:
Module Description
JAZ-S Spectrometer and grating (up to 8 can be configured in a stack)
JAZ-DPU Processor (CPU), OLED display and keypad
JAZ-E Ethernet and memory module. Includes one slot for an SD card (up to 2 GB).
JAZ-B Battery (lithium-ion) and memory module. Includes two slots for an SD card (up to 2 GB
each).
JAZ-UV-VIS Deuterium-tungsten halogen light source
JAZ-VIS-NIR Tungsten-halogen light source
JAZ-L640 640 nm red LED
JAZ-L590 590 nm yellow LED
JAZ-L450 450 nm blue LED
JAZ-L395 395 nm UV LED
JAZ-WHITE White LED
A Jaz Combo consists of a combination of up to three JAZ-S spectrometer modules and a JAZ-DPU
module.
