B: Specifications

020-00000-000-02-201207

23

Location of Maya2000 Series 30-Pin Accessory Connector

30-Pin Accessory Connector Pinout Diagram

When facing the 30-pin Accessory Connector on the front of the vertical wall of the Maya2000 Series
Spectrometer, pin numbering is as follows:

USB

Port

2

4

6

8

10

12

14

16

18

20

22

24

26

28

30

1

3

5

7

9

11

13

15

17

19

21

23

25

27

29

30-Pin Accessory Connector Pinout Diagram

30-Pin Accessory Connector – Pin Definitions and

Descriptions

The following table contains information regarding the function of each pin in the Maya2000 Series
Spectrometer’s 30-Pin Accessory Connector:

Pin # Function

Input/Output

Description

1

N/A

N/A

Reserved

2

N/A

N/A

Reserved
