Axial Lead & Cartridge Fuses
3.6 X 10 mm > Fast-Acting > 876 Series
876 Series
Please refer to www.littelfuse.com/series/876.html for current information.
876 Series
876 Series Fuse,
Lead-free 3.6 x 10 mm, Fast–Acting Fuse
Agency
Agency File Number
Ampere Range
40022494
0.125 – 0.630A
1.6 – 5A
E10480
0.125 – 5A
Features
Applications
Electrical Characteristics
% of Ampere
Rating
Opening Time
150%
60 minutes, Minimum
210%
30 minutes, Maximum
275%
10 ms., Min.; 3 sec. Max.
400%
3 ms., Min.; 300 ms. Max.
1000%
20 ms. Max.
t %FTJHOFEUPNFFU
*&$4UBOEBSE
Sheet 3
t 'BTU"DUJOH DFSBNJD
CPEZGVTFJOB
DPNQBDUQBDLBHF
t 4JOHMF1JHUBJM"YJBM
-FBEGPSNBU
t 1CGSFF 3P)4
DPNQMJBOU
t "WBJMBCMFJOSBUJOHTPG
UP"NQFSFT
Amp Code
Ampere
Rating
(A)
Voltage
Rating
(V)
Interrupting
Rating
Nominal
Cold
Resistance
(Ohms)
Nominal
Melting
I
2
t (A
2
sec)
Nominal
Voltage
Drop (mV)
Nominal
Power
Dissipation
(mW)
Agency Approvals
.125
0.125
250
35A @ 250 V AC
1.066
0.020
168
60
x
x
.160
0.160
250
35A @ 250 V AC
1.000
0.028
183
92
x
x
.250
0.250
250
35A @ 250 V AC
0.573
0.110
87
62
x
x
.630
0.630
250
35A @ 250 V AC
0.131
0.170
102
221
x
x
01.6
1.6
250
35A @ 250 V AC
0.0388
1.8
70
382
x
x
002.
2.0
250
35A @ 250 V AC
0.0329
2.51
70
470
x
x
004.
4.0
250
40A @ 250 V AC
0.0149
14.64
70
985
x
x
005.
5.0
250
50A @ 250 V AC
0.0111
26.85
66
1200
x
x
Electrical Characteristics
t 5IJTTQBDFTBWJOHGVTFJTJEFBMMZTVJUFEGPSMJHIUJOH
QPXFSTVQQMZ BOEBEBQUFSBQQMJDBUJPOT
/PUFT
$PMESFTJTUBODFNFBTVSFEBUMFTTUIBOPGSBUFEDVSSFOUBU$
Description
4JOHMF1JHUBJM"YJBM-FBEYNN'BTU"DUJOH'VTF
