Surface Mount – 1500W > SMCJ series
Electrical Characteristics
(T
A
=25°C unless otherwise noted)
Part
Number
(Uni)
Part
Number
(Bi)
Marking
Reverse
Stand off
Voltage
V
R
(Volts)
Breakdown
Voltage V
BR
(Volts) @ I
T
Test
Current
I
T
(mA)
Maximum
Clamping
Voltage V
C
@ I
pp
(V)
Maximum
Peak
Pulse
Current I
pp
(A)
Maximum
Reverse
Leakage I
R
@ V
R
(µA)
Agency
Approval
UNI BI MIN MAX
SMCJ5.0A SMCJ5.0CA GDE BDE 5.0 6.40 7.00 10 9.2 163.0 800 X
SMCJ6.0A SMCJ6.0CA GDG BDG 6.0 6.67 7.37 10 10.3 145.7 800 X
SMCJ6.5A SMCJ6.5CA GDK BDK 6.5 7.22 7.98 10 11.2 134.0 500 X
SMCJ7.0A SMCJ7.0CA GDM BDM 7.0 7.78 8.60 10 12.0 125.0 200 X
SMCJ7.5A SMCJ7.5CA GDP BDP 7.5 8.33 9.21 1 12.9 116.3 100 X
SMCJ8.0A SMCJ8.0CA GDR BDR 8.0 8.89 9.83 1 13.6 110.3 50 X
SMCJ8.5A SMCJ8.5CA GDT BDT 8.5 9.44 10.40 1 14.4 104.2 20 X
SMCJ9.0A SMCJ9.0CA GDV BDV 9.0 10.00 11.10 1 15.4 97.4 10 X
SMCJ10A SMCJ10CA GDX BDX 10.0 11.10 12.30 1 17.0 88.3 5 X
SMCJ11A SMCJ11CA GDZ BDZ 11.0 12.20 13.50 1 18.2 82.5 1 X
SMCJ12A SMCJ12CA GEE BEE 12.0 13.30 14.70 1 19.9 75.4 1 X
SMCJ13A SMCJ13CA GEG BEG 13.0 14.40 15.90 1 21.5 69.8 1 X
SMCJ14A SMCJ14CA GEK BEK 14.0 15.60 17.20 1 23.2 64.7 1 X
SMCJ15A SMCJ15CA GEM BEM 15.0 16.70 18.50 1 24.4 61.5 1 X
SMCJ16A SMCJ16CA GEP BEP 16.0 17.80 19.70 1 26.0 57.7 1 X
SMCJ17A SMCJ17CA GER BER 17.0 18.90 20.90 1 27.6 54.4 1 X
SMCJ18A SMCJ18CA GET BET 18.0 20.00 22.10 1 29.2 51.4 1 X
SMCJ20A SMCJ20CA GEV BEV 20.0 22.20 24.50 1 32.4 46.3 1 X
SMCJ22A SMCJ22CA GEX BEX 22.0 24.40 26.90 1 35.5 42.3 1 X
SMCJ24A SMCJ24CA GEZ BEZ 24.0 26.70 29.50 1 38.9 38.6 1 X
SMCJ26A SMCJ26CA GFE BFE 26.0 28.90 31.90 1 42.1 35.7 1 X
SMCJ28A SMCJ28CA GFG BFG 28.0 31.10 34.40 1 45.4 33.1 1 X
SMCJ30A SMCJ30CA GFK BFK 30.0 33.30 36.80 1 48.4 31.0 1 X
SMCJ33A SMCJ33CA GFM BFM 33.0 36.70 40.60 1 53.3 28.2 1 X
SMCJ36A SMCJ36CA GFP BFP 36.0 40.00 44.20 1 58.1 25.9 1 X
SMCJ40A SMCJ40CA GFR BFR 40.0 44.40 49.10 1 64.5 23.3 1 X
SMCJ43A SMCJ43CA GFT BFT 43.0 47.80 52.80 1 69.4 21.7 1 X
SMCJ45A SMCJ45CA GFV BFV 45.0 50.00 55.30 1 72.7 20.6 1 X
SMCJ48A SMCJ48CA GFX BFX 48.0 53.30 58.90 1 77.4 19.4 1 X
SMCJ51A SMCJ51CA GFZ BFZ 51.0 56.70 62.70 1 82.4 18.2 1 X
SMCJ54A SMCJ54CA GGE BGE 54.0 60.00 66.30 1 87.1 17.3 1 X
SMCJ58A SMCJ58CA GGG BGG 58.0 64.40 71.20 1 93.6 16.1 1 X
SMCJ60A SMCJ60CA GGK BGK 60.0 66.70 73.70 1 96.8 15.5 1 X
SMCJ64A SMCJ64CA GGM BGM 64.0 71.10 78.60 1 103.0 14.6 1 X
SMCJ70A SMCJ70CA GGP BGP 70.0 77.80 86.00 1 113.0 13.3 1 X
SMCJ75A SMCJ75CA GGR BGR 75.0 83.30 92.10 1 121.0 12.4 1 X
SMCJ78A SMCJ78CA GGT BGT 78.0 86.70 95.80 1 126.0 11.9 1 X
SMCJ85A SMCJ85CA GGV BGV 85.0 94.40 104.00 1 137.0 11.0 1 X
SMCJ90A SMCJ90CA GGX BGX 90.0 100.00 111.00 1 146.0 10.3 1 X
SMCJ100A SMCJ100CA GGZ BGZ 100.0 111.00 123.00 1 162.0 9.3 1 X
SMCJ110A SMCJ110CA GHE BHE 110.0 122.00 135.00 1 177.0 8.5 1 X
SMCJ120A SMCJ120CA GHG BHG 120.0 133.00 147.00 1 193.0 7.8 1 X
SMCJ130A SMCJ130CA GHK BHK 130.0 144.00 159.00 1 209.0 7.2 1 X
SMCJ150A SMCJ150CA GHM BHM 150.0 167.00 185.00 1 243.0 6.2 1 X
SMCJ160A SMCJ160CA GHP BHP 160.0 178.00 197.00 1 259.0 5.8 1 X
SMCJ170A SMCJ170CA GHR BHR 170.0 189.00 209.00 1 275.0 5.5 1 X
SMCJ180A SMCJ180CA GHT BHT 180.0 201.00 222.00 1 292.0 5.1 1 X
SMCJ200A SMCJ200CA GHV BHV 200.0 224.00 247.00 1 324.0 4.6 1 X
SMCJ220A SMCJ220CA GHX BHX 220.0 246.00 272.00 1 356.0 4.2 1 X
SMCJ250A SMCJ250CA GHZ BHZ 250.0 279.00 309.00 1 405.0 3.7 1 X
SMCJ300A SMCJ300CA GJE BJE 300.0 335.00 371.00 1 486.0 3.1 1 X
SMCJ350A SMCJ350CA GJG BJG 350.0 391.00 432.00 1 567.0 2.6 1 X
SMCJ400A SMCJ400CA GJK BJK 400.0 447.00 494.00 1 648.0 2.3 1 X
SMCJ440A SMCJ440CA GJM BJM 440.0 492.00 543.00 1 713.0 2.1 1 X
For bidirectional type having V
R
of 10 volts and less, the I
R
limit is double.
For parts without A , the V
BR
is + 10% and V
C
is 5% higher than with A parts.
