PLED Open LED Protectors
Revision: June 16, 2011
©2011 Littelfuse, Inc.
Specifications are subject to change without notice.
PLED Series
PLED Series
DO-214 Embossed Carrier Reel Pack (RP)
Meets all EIA-481-1 Standards
0.472
(12.0)
0.36
(9.2)
0.315
(8.0)
0.157
(4.0)
0.49
(12.4)
0.512 (13.0) Arbor
Hole Dia
.
12.99
(330.0)
Dimensions
are in inches
(and millimeters).
Direction of Feed
0.059
DI
A
(1.5)
Cover tape
Cathode bar on this side
