TwinChip™ Series - DO-15
Description
TwinChip™ Series DO-15 are very low capacitance
SIDACtor
® devices designed to protect broadband
CPE equipment, such as VoIP and xDSL modems from
damaging overvoltage transients. The series provides a
through-hole solution that enables equipment to comply
with global regulatory standards while limiting the impact to
broadband signals.
Electrical Characteristics
Features & Benefits
t%JGGFSFOUJBMQSPUFDUJPO
t-PXJOTFSUJPOMPTT
t-PXDBQBDJUBODF
t(%5DPNQBUJCMFBYJBM
footprint
t-PXWPMUBHFPWFSTIPPU
t%PFTOPUEFHSBEFXJUIVTF
t'BJMTTIPSUDJSDVJUXIFO
surged in excess of ratings
Agency Approvals
Agency Agency File Number
E133083
Schematic Symbol
Pinout Designation
NOT APPLICABLE
t5*""
t5*"#
t*56,#BTJD-FWFM
t(3*OUSBCVJMEJOH
t*&$
t:%5
t:%5
t:%5
Applicable Global Standards
Part Number Marking
V
DRM
@
I
DRM
=5μA
V
S
@
100V/μs
I
H
I
S
I
T
V
T
@ I
T
= 2.2 Amps
Capacitance @1MHz
@ 2V bias
V min V max mA min mA max A max V max pF min pF max
P2602GALRP P262A 220 300 150 800 2.2 8 15 25
P3002GALRP P30A 280 360 150 800 2.2 8 10 20
P3502GALRP P352A 320 400 150 800 2.2 8 10 20
P2602GBLRP P262B 220 300 150 800 2.2 8 15 25
P3002GBLRP P30B 280 360 150 800 2.2 8 10 20
P3502GBLRP P352B 320 400 150 800 2.2 8 10 20
Notes:
- Absolute maximum ratings measured at T
A
= 25ºC (unless otherwise noted).
- Devices are bi-directional (unless otherwise noted).
