Cartridge Fuse Blocks
Ordering NO.* Catalog NO. No. of poles Width (b) Clip/Terminal material packaging Available
Solder Type Terminals
0254 0001Z 254 001 1 0.35” Brass Z
0254 0002Z 254 002 2 0.80” Brass Z
0254 0003Z 254 003 3 1.25” Brass Z
0254 0004Z 254 004 4 1.70” Brass Z
0254 0005Z 254 005 5 2.15” Brass Z
0254 0006Z 254 006 6 2.60” Brass Z
0254 0007Z 254 007 7 3.05” Brass Z
0254 0008Z 254 008 8 3.50” Brass Z
NEMA Style .110” q.C. Terminals
0254 0201Z 254 201 1 0.35” Brass Z
0254 0202Z 254 202 2 0.80” Brass Z
0254 0203Z 254 203 3 1.25” Brass Z
0254 0204Z 254 204 4 1.70” Brass Z
0254 0205Z 254 205 5 2.15” Brass Z
0254 0206Z 254 206 6 2.60” Brass Z
0254 0207Z 254 207 7 3.05” Brass Z
0254 0208Z 254 208 8 3.50” Brass Z
P.C. Board Mount
02540101Z 254 101 1 0.35” Brass Z
02540121Z 254 121 1 0.35” Beryllium Copper Z
Ordering Information
“Z” =for bulk package
Add Suffix:
