© 2013 Littelfuse, Inc.

Specifications are subject to change without notice.

Revised: 04/24/13

TVS Diode Arrays

(SPA

®

Diodes)

Low Capacitance ESD Protection - SP3011 Series

Embossed Carrier Tape & Reel Specification — µDFN-14

Package Dimensions — µDFN-14 (3.5x1.35x0.5mm)

Symbol

Millimeters

A0

1.58 ± 0.10

B0

3.73 ± 0.10

D0

0.60 + 0.05

D1

Ø 0.60 + 0.05

E

1.75 ± 0.10

F

5.50 ± 0.05

K0

0.68 ± 0.10

P0

2.00 ± 0.05

P1

4.00 ± 0.10

P2

4.00 ± 0.10

T

0.28 ± 0.02

W

12.00 + 0.30 /- 0.10

P0

D0

E

F

P1

P2

D1

W

T

B0

K0

A0

User Feeding Direction

Pin 1 Location

Package

µDFN-14

(3.5x1.35x0.5mm)

JEDEC

MO-229

Symbol

Millimeters

Inches

Min

Nom

Max

Min

Nom

Max

A

0.45

0.50

0.55

0.018

0.020

0.022

A1

0.00

0.02

0.05

0.000

0.001

0.002

A2

0.203 Ref

0.008 Ref

b

0.15

0.20

0.25

0.006

0.008

0.012

D

3.40

3.50

3.60

0.134

0.138

0.142

D2

-

-

-

-

-

-

E

1.25

1.35

1.45

0.050

0.054

0.058

E1

-

-

-

-

-

-

e

0.500 BSC

0.020 BSC

L

0.25

0.30

0.35

0.010

0.012

0.014

D

E

B

Top View

A

Bottom View

Side View

PIN 1 Index Area

1 2 3 4

A

C

b

A1 A2

Seating
Plane

Pin 1 Identification
Chamfer 0.10X45º

Notes:
1. Dimension and tolerancing comform to ASME Y14.5M-1994.
2. Controlling dimensions: Millimeter. Converted Inch dimensions are not necessarily

exact.

Soldering Pad Layout

Recomended

Symbol

Millimeter

Inches
