FUSEHOLDERS
Visit our web site at www.littelfuse.com
IN-LINE FUSEHOLDERS & POWER FEED DEVICES 13
O
R
IG
IN
AL
EQUI
PM
E
N
T
S
U P P LIER
OEM
ATO ® Fuse In-line Panel Mount Fuseholder
Versatile fuseholder for in-line or snap mount panel applica-
tions. Interlock body design allows fuseholders to be
snapped together. Use with ATO
® Fuse 1 to 20 amps.
Supplied with 8" loop of 14 gauge black wire.
Part No.
AFH 1
US
Carded No.
AFH 1 BP
Canadian
Carded No.
AFH 1 CABP
ATO ® Fuse Heavy Duty In-line
Panel Mount Fuseholder
Use with ATO ® Fuse 25 and 30 amp fuses. Same as AFH 1
except supplied with 8" loop of 10 gauge orange wire.
Part No.
AFH 2
US
Carded No.
AFH 2 BP
Canadian
Carded No.
AFH 2 CABP
ATO ® Add-A-Circuit ™ Kit
Allows easy installation of additional circuits without cutting
or splicing. Turns one fuse slot into two while providing pro-
tection for both circuits. Maintains new car warranty. Use
with ATO
® Fuses up to 10 amps. Includes ATO 3, 5, 7.5 and
10 amps.
Part No.
FHA 200
US & Canadian
Carded No.
FHA 200 BP
MINI ® Add-A-Circuit ™ Kit
Same as ATO Add-A-Circuit except for use with MINI ®
Fuses up to 10 amps. Includes MINI 3, 5, 7.5 and 10 amps.
Part No.
FHM 200
US & Canadian
Carded No.
FHM 200 BP
Battery Power Feed Kit
Attaches directly to battery terminal. Allows the addition of
up to 3 circuits. Includes MINI Fuse In-line Fuseholder with
protective cap. Also can be used as a frame ground.
Constructed of durable brass for optimal conductivity.
US & Canadian
Carded No.
BPF 1 BP
Caution: Fusetaps are not a recommended alternative for adding
circuits because they can overstress the terminals in the fuse block. This
situation can create a loose fitting fuse, which in turn produces exces-
sive heat, which can cause nuisance blows, even melting of the fuse
and fuse block and possibly an expensive repair in the future. When a
fusetap is used, in many cases there is no fuse protecting the new
circuit, a condition which can also present a hazard.
