SLIC Protection
Fix
ed
V
oltage Enh. Single
Dimensions — MS-012
Dimension
Inches Millimeters
MIN MAX MIN MAX
A 0.053 0.069 1.35 1.75
A1 0.004 0.010 0.10 0.25
A2 0.043 0.065 1.25 1.65
# 0.012 0.020 0.31 0.51
C 0.007 0.010 0.17 0.25
D 0.189 0.197 4.80 5.00
E 0.228 0.244 5.80 6.20
E1 0.150 0.157 3.80 4.00
e #4$ #4$
L 0.016 0.050 0.40 1.27
#4$Basic Spacing between Centers
Packing Options
Package Type Description Quantity Added Suffix Industry Standard
D
MS-012 SMT 8-pin
40*$5BQFBOE3FFM
Pack
2500 /" EIA-481-D
Tape and Reel Specifications — MS-012
o
Recommended
Soldering Pad Outline
(Reference Only)
Part Marking
o
XXXXXF1E
XXXXX
Part Number Code
(Refer to Electrical Characteristics Table)
Date Code
Part Numbering
CONSTRUCTION VARIABLE
P: SIDACtor
SINGLE ENHANCED TYPE
P -1E
MEDIAN VOLTAGE
PACKAGE TYPE
xxx 1 DF
I
PP
RATING
0.8
(0.03)
1.50
(.059)
4.0
(.158)
5.5
(.216)
2.0
(.079)
8.0
(.315)
6.4
(.252)
12.0
(.472)
Direction of Feed
ø MIN.
Carrier Tape
Embossment
Cover
Tape
DIMENSIONS ARE:
MILLIMETERS
(INCHES)
0 MIN.
MIN.
0.40
(0.016)
2.1
(.083)
1.55
(.061)
0.49
(12.4)
0.512 (13.0) Arbor
Hole Dia.
12.99
(330.0)
Dimensions are in inches
(and millimeters).
Direction of Feed
o
