MIDI
®
STYLE BOLT-DOWN FUSE RATED 32V
Dimensions
Dimensions in mm
MIDI Rerating Curve
85
90
95
100
105
110
115
-40
-30
-20
-10
0
10
20
30
40
50
60
70
80
90
100
110
120
Ambient Temperature (C)
R
er
ating
F
ac
to
r (%
R
at
ed
Cu
rr
ent
)
Temperature Rerating Curve
Time-Current Characteristic Curves
Part Number
“A”
mm (inch)
“B”
mm (inch)
“C”
mm (inch)
0498023._
0.41 (0.016)
4.0 (0.157)
8.0 (0.315)
0498030._
0.41 (0.016)
4.0 (0.157)
8.0 (0.315)
0498040._
0.41 (0.016)
4.0 (0.157)
8.0 (0.315)
0498050._
0.41 (0.016)
4.0 (0.157)
8.0 (0.315)
0498060._
0.41 (0.016)
4.0 (0.157)
8.0 (0.315)
0498070._
0.41 (0.016)
4.0 (0.157)
8.0 (0.315)
0498080._
0.41 (0.016)
4.0 (0.157)
8.0 (0.315)
0498100._
0.63 (0.025)
4.3 (0.169)
8.3 (0.327)
0498125._
0.63 (0.025)
4.3 (0.169)
8.3 (0.327)
0498150._
0.63 (0.025)
4.3 (0.169)
8.3 (0.327)
0498175._
0.63 (0.025)
4.3 (0.169)
8.3 (0.327)
0498200._
0.63 (0.025)
4.3 (0.169)
8.3 (0.327)
Bolt-down Fuses
0.01
0.1
1
10
100
1000
10
100
1000
10000
TIM
E IN
S
EC
O
N
D
S
CURRENT IN AMPERES
TIME-CURRENT CHARACTERISTIC CURVES
40
A
30
A
50
A
60
A
70
A
80
A
10
0A
12
5A
15
0A
17
5A
20
0A
23
A
