Teccor ® brand Thyristors
0.8 Amp Sensitive SCRs
EC103xx & SxSx Series
Electrical Characteristics (T
J
= 25°C, unless otherwise specified)
Symbol Test Conditions
Value
Unit SxS1
EC103X1
SxS2
EC103X2
SxS /
2N6565
EC103X
SxS3
EC103X3
I
GT V
D
= 6V; R
L
= 100 :
MAX. 12 50 200 500 μA
V
GT
MAX. 0.8 V
dv/dt V
D
= V
DRM
; R
GK
= 1kΩ
400V
MIN.
20 25 30 40
V/μs
600V 10 10 15 20
V
GD
V
D
= V
DRM
; R
L
= 3.3 k :; T
J
= 110°C MIN. 0.2 0.25 V
I
H
I
T
= 20mA (initial), R
GK
= 1k : MAX. 5 8 mA
t
q
(1) MAX. 60 50 45 μs
t
gt
I
G
= 2 x I
GT
; PW = 15μs; I
T
= 1.6A TYP. 2 5 20 30 μs
(1) I
T
=1A; t
p
=50μs; dv/dt=5V/μs; di/dt=-5A/μs
Static Characteristics
Symbol Test Conditions Value Unit
V
TM
I
T
= 1.2A; t
p
= 380 μs MAX. 1.7 V
I
DRM
/ I
RRM
V
DRM
= V
RRM
R
GK
= 1k :
T
J
= 25°C
MAX.
1
μA T
J
= 100°C 50
T
J
= 110°C 100
Thermal Resistances
Symbol Parameter Value Unit
R
T(J-C)
Junction to case (AC)
EC103xy/2N6565 75
°C/W
SxSy 60*
R
T(J-A)
Junction to ambient EC103xy/2N6565 160 °C/W
Notes: x = voltage, y = sensitivity
* = Mounted on 1 cm
2 copper (two-ounce) foil surface
