CLEAR MIDI ® STYLE BOLT-DOWN FUSE RATED 32V
Dimensions
Dimensions in mm
Temperature Rerating Curve
Time-Current Characteristic Curves
MIDI Rerating Curve
85
90
95
100
105
110
115
-40 -30 -20 -10 0 10 20 30 40 50 60 70 80 90 100 110 120
Ambient Temperature (C)
R
e
ra
ting
F
ac
to
r
(%
R
a te
d
Cu
rr
e nt
)
30A 40A 50A 60A 70A 80A 100A 125A 150A 200A 175A
1000
100
10
1
0.1
0.01
10000 1000 100 10
TIME IN SECONDS
Ratings
Part Number
“A”
mm (inches)
“B”
mm (inches)
“C”
mm (inches)
0498030._ .41 (.016) 4.0 (.157) 8.0 (.315)
0498040._ .41 (.016) 4.0 (.157) 8.0 (.315)
0498050._ .41 (.016) 4.0 (.157) 8.0 (.315)
0498060._ .41 (.016) 4.0 (.157) 8.0 (.315)
0498070._ .41 (.016) 4.0 (.157) 8.0 (.315)
0498080._ .41 (.016) 4.0 (.157) 8.0 (.315)
0498100._ 0.63 (.025) 4.3 (.169) 8.3 (.327)
0498125._ 0.63 (.025) 4.3 (.169) 8.3 (.327)
0498150._ 0.63 (.025) 4.3 (.169) 8.3 (.327)
0498175._ 0.63 (.025) 4.3 (.169) 8.3 (.327)
0498200._ 0.63 (.025) 4.3 (.169) 8.3 (.327)
Bolt-down Fuses
