Littelfuse SDP Series 5x6 QFN - Manual (Page 2)

SIDACtor ® Protection Thyristors
36
Revised: February 22, 2011
© 2011 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to www.littelfuse.com for current information.
Broadband Optimized ™ Protection
Series
I
PP
I
TSM
2x10μs 1.2x50μs/8x20μs 10x700/5x310μs 10x1000μs 600V
RMS
1 Cycle
A min A min A min A min A
RMS
B 250 230 100 75 25
Surge Ratings
Thermal Considerations
I
H
I
T
I
S
I
DRM
V
DRM
V
T
+V -V
+I
-I
V
S
V-I Characteristics
Parameter Name Test Conditions Value Units
I
TSM
Maximum non-repetitive
on-state current, 50/60 Hz
0.5s 6.5
A
1s 4.6
2s 3.4
5s 2.3
30s 1.3
900s 0.73
50/60 Hz Ratings
0
10
20
30
40
50
0 0 1 0 1 1 1 . 0
Line Voltage (V)
Capacitance (pF)
Tip-Ring
Tip-GND / Ring-GND
Capacitance vs. Voltage
Package Symbol Parameter Value Unit
T
J
Junction Temperature UP °C
T
STG
Storage Temperature Range UP °C
R
0JA
Thermal Resistance: Junction to Ambient 100 °C/W
5 x 6 QFN
Notes:
- Peak pulse current rating (I
PP
) is repetitive and guaranteed for the life of the product.
- I
PP
SBUJOHTBQQMJDBCMFPWFSUFNQFSBUVSFSBOHFPG$UP$
- The device must initially be in thermal equilibrium with -40°C < T
J
<¡$
