Axial Leaded – 1500W > LCE series
Part Numbering System
V
R
VOLTAGE CODE
(Refer to the Electrical Characteristics table)
OPTION CODE:
BLANK Reel Tape
-B Bulk Packaging
SERIES CODE
LCE xxx A X
TYPE CODE:
A Uni-Directional (5% V
BR
Voltage Tolerance)
Part Marking System
F
LCEXXX
YYWW
Trace Code Marking
YY:Year Code
WW: Week Code
Product Type
Littelfuse Logo
Cathode Band
Packaging
Part Number Component Package Quantity Packaging Option Packaging Specification
LCExxxXX DO-201 1200 Tape & Reel EIA STD RS-296
LCExxxXX-B DO-201 500 BULK Littelfuse Spec.
Schematic
Tape and Reel Specification
2.063+0.079/-0.039 2.56
0.394+/-0.020
2.75
0.047
(330.2)
Recess Depth Max. 0.75 (19.05)
Off Center
either side
0.028(0.7)
Dimensions are in
inches/mm
0.236
(65.0)
(10.0+/-0.5)
(53.0+2.0/-1.0)
(6.0) (1.2)
(69.85)
13.0
(76.2)
3.0
0.68
(17.27)
Direction of Feed
Transient
Voltage
Suppressor
Diode
