SIDACtor ® Protection Thyristors
149
Revised: February 22, 2011
© 2011 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to www.littelfuse.com for current information.
Baseband Protection (Voice-DS1)
Part Number
Pin 3-4
Tip-Ring
Pins 1 & 6-3, 1 & 6-4
Tip-Ground, Ring-Ground
pF min pF max pF min pF max
P1553UALxx 20 95 10 60
P1803UALxx 20 85 10 55
P2103UALxx 15 85 10 55
P2353UALxx 15 75 10 50
P2703UALxx 15 75 10 50
P3203UALxx 15 70 10 45
P3403UALxx 15 65 10 45
P5103UALxx 10 60 10 40
P1553UBLxx 25 95 15 60
P1803UBLxx 25 85 15 55
P2103UBLxx 20 85 15 55
P2353UBLxx 20 75 15 50
P2703UBLxx 20 75 10 50
P3203UBLxx 20 70 10 45
P3403UBLxx 15 65 10 45
P5103UBLxx 15 60 10 40
P1553UCLxx 30 95 20 60
P1803UCLxx 30 85 15 55
P2103UCLxx 30 85 15 55
P2353UCLxx 25 75 15 50
P2703UCLxx 25 75 15 50
P3203UCLxx 25 70 15 45
P3403UCLxx 20 65 15 45
P5103UCLxx 20 60 10 40
Capacitance Values
Note: Off-state capacitance (C
O
) is measured at 1 MHz with a 2 V bias.
Electrical Characteristics (continued)
Part
Number
Part
Marking
V
DRM
@l
DRM
=5μA
V
S
@100V/μs
V
DRM
@l
DRM
=5μA
V
S
@100V/μs
V
T
I
S
I
T
I
H
Capacitance
V min V max V min V max
V max mA max A max mA min
Pins 1 & 6-3, 1 & 6-4 Pins 3-4
P1553UBLxx P1553UB 130 180 130 180 8 800 2.2 150
See
Capacitance
Values table
P1803UBLxx P1803UB 150 210 150 210 8 800 2.2 150
P2103UBLxx P2103UB 170 250 170 250 8 800 2.2 150
P2353UBLxx P2353UB 200 270 200 270 8 800 2.2 150
P2703UBLxx P2703UB 230 300 230 300 8 800 2.2 150
P3203UBLxx P3203UB 270 350 270 350 8 800 2.2 150
P3403UBLxx P3403UB 300 400 300 400 8 800 2.2 150
P5103UBLxx P5103UB 420 600 420 600 8 800 2.2 150
P1553UCLxx P1553UC 130 180 130 180 8 800 2.2 150
P1803UCLxx P1803UC 150 210 150 210 8 800 2.2 150
P2103UCLxx P2103UC 170 250 170 250 8 800 2.2 150
P2353UCLxx P2353UC 200 270 200 270 8 800 2.2 150
P2703UCLxx P2703UC 230 300 230 300 8 800 2.2 150
P3203UCLxx P3203UC 270 350 270 350 8 800 2.2 150
P3403UCLxx P3403UC 300 400 300 400 8 800 2.2 150
P5103UCLxx P5103UC 420 600 420 600 8 800 2.2 150
